Arctic Air 50 Inch Direct Drive Super Flo Fiberglass Fan - 3 Phase
SKU:
11010371
Write a Review
Write a Review
Arctic Air 50 Inch Direct Drive Super Flo Fiberglass Fan - 3 Phase
$1,174.45
The Super Flo direct driven fans are some of the among powerful and efficient fans available in the market today.
Their smooth bell shaped intake is designed for optimum performance and has a balanced exhaust opening for maximum air velocity and distance coverage. This 50 inch fan is constructed from fiberglass for a lightweight housing that is easier to handle than heavy metal housing fans. The fiberglass housing is corrosion-resistant and designed for durability in the harshest environments.
Super Flo 50” Direct Drive Fan Key Features:
- Direct Drive Motor - 1.5 hp
- The fan has a built in VFD variable speed motor that can be controlled by a controller that has a 0-10 volt output.
- Designed for optimum air throw and coverage
- Well balanced and strong blade design for years of trouble-free service
- Motors are totally enclosed, high efficiency with sealed ball bearing
- Easy to clean and corrosion-resistant fiberglass housing
- All fans have a 3 blade galvanized propeller
- Front and rear guards are included
- EC Motor with built-in VFD for variable speed control
| VOLT | HP (KW) | Phase | RPM | Speed | Watts | LPF | LPF/KW | CFM | CFM/Watt |
| 230/460 | 1.5 (1.2 KW) | 1/3 | 600 | Variable | 1200 | 24.2 | 20 | 22900 | 19 |
| 230/460 | 1.4(1.04 KW) | 1/3 | 570 | Variable | 1040 | 21.1 | 20.3 | 21400 | 20.6 |
| 230/460 | 1.2 (.89 KW) | 1/3 | 540 | Variable | 890 | 19.1 | 21.5 | 20300 | 22.9 |
| 230/460 | .85 (.63 KW) | 1/3 | 480 | Variable | 630 | 15.63 | 24.7 | 18400 | 29.1 |
| 230/460 | .60 (.49 KW) | 1/3 | 420 | Variable | 438 | 12 | 27.3 | 16100 | 36.7 |
| 230/460 | .25 (.18 KW) | 1/3 | 300 | Variable | 183 | 6 | 32.9 | 11400 | 62.4 |
| Standard/Approvals | CSA/CSAus Certified |
| Application | For animal cooling in dairy or in environments needing corrosion resistance like swine and poultry |
| Material | Fiberglass |
| Type | Direct Drive |
| Voltage Rating | 230 / 460 VAC |
| Horsepower | 1.5 hp |
| Blade Diameter | 50 in |
| Number of Speeds | 3 |
| Propeller | 3 Blades |
| Includes | EC Motor with built-in VFD for variable speed control |
| Watts | 1100 |
| RPMs | 600 |
| Hertz | 60 |
| Ibf/kW | 21.3 |
| Thrust CFM | 22,228 |
