20 Inch Variable Speed 1/3 HP 6000 CFM Basket Fan
$212.71
In Stock
$212.71
DETAILS
Our high velocity basket fan is one of the most powerful and efficient basket fans available. The fan’s tapered intake and exhaust is designed for optimum performance, maximum air velocity and distance coverage.
This fan is designed for the harshest environments. The standard OSHA safety guards mean you can mount this fan at any height. Running on a ⅓ horsepower motor, this fan can generate 6,000 cu. ft./min of airflow. Mounting Bracket Included
6,000 CFM 20” Wall/Ceiling Basket Fan Features:
- Versatile wall and ceiling mount pivots 180 deg and fan can turn 360 deg. Mounting brackets included.
- Zinc plated wire guards with white powder coated paint for exceptional corrosion resistance
- Motors are totally enclosed, high efficiency with sealed ball bearing
- Easy to clean and has no corners for dirt build-up
- Rotors have been balanced to reduce noise vibration and prolong life
- Motor enclosures have been machined to <0.5 mm to reduce rotor shaft play
- Standard OSHA safety guards on intake and exhaust
- Industry leading fan efficiency, up to 26 cfm/W
- Capacitor rating 450 VAC, 10000 hr for extended life
- These fans are dual voltage, so they do not come pre-wired
- Most powerful basket fans in the market today based on size and motor horsepower
- Well balanced and strong blade design for years of trouble free service
- Copper winding
- These fans are dual voltage, so they do not come pre-wired
- Does not come with Cord.
*** These Fans can only be variable speed when they are wired into a control ***
SPECIFICATIONS
| Standard/Approvals | cCSAus CertifiedOSHA ApprovedBess Labs Certified |
| Application | For animal cooling in dairy or corrosive environments like swine and poultry, people cooling in factories, warehouses and sporting events, air de-stratification and insect control |
| With | With Ceiling/Wall Mount Bracket |
| Type | High Velocity Variable Speed |
| Flow Rate | 6000 cfm |
| Voltage Rating | 115/230 VAC |
| Power Rating | 1/3 hp |
| Amperage Rating | 2.05/4.18 A |
| Frequency Rating | 50/60 Hz |
| Speed | 1725 rpm |
| Blade Material | Aluminum |
| Blade Size | 20 in |
| Number of Blades | 3 |
| Mounting Type | Ceiling/Wall |
SPECIFICATIONS
| Standard/Approvals | cCSAus CertifiedOSHA ApprovedBess Labs Certified |
| Application | For animal cooling in dairy or corrosive environments like swine and poultry, people cooling in factories, warehouses and sporting events, air de-stratification and insect control |
| With | With Ceiling/Wall Mount Bracket |
| Type | High Velocity Variable Speed |
| Flow Rate | 6000 cfm |
| Voltage Rating | 115/230 VAC |
| Power Rating | 1/3 hp |
| Amperage Rating | 2.05/4.18 A |
| Frequency Rating | 50/60 Hz |
| Speed | 1725 rpm |
| Blade Material | Aluminum |
| Blade Size | 20 in |
| Number of Blades | 3 |
| Mounting Type | Ceiling/Wall |
CUSTOMER REVIEWS
1 Review
Posted by Earl on Jun 26, 2024
High Volume Fan
The horses love standing in front of the fan. It's loud but runs continuously in a fairly harsh environment
